DOUBLE DOWNLIGHT
The ARCH PRO SQUARE TWIN from the Chiara ARCH PRO range is a small square double downlight with a soft gradient baffle. Thanks to its neat 155 x 85mm size, it’s a perfectly neat architectural downlight suitable for hospitality, retail and high end residential applications.
So if you are after an adjustable deep recessed downlight for optimum glare control – the PRO SQUARE TWIN offers exactly that. Select either a black or white bezel, 4 contemporary baffle options and 3 accessories. With a further choice of 4 different engines, PRO SQUARE TWIN can give the user different types of control.
And the best thing about this double downlight? It’s the subtle look and feel of this down lighter alongside the easy tool-free maintenance, as the light source and the driver are easily accessible from below.
The PRO SQUARE TWIN offers 3 colour temperature options (2700K, 3000K and 4000K) and over 12 output options (619Lm to 1235Lm) making this attractive twin adjustable downlight suitable for a range of residential and commercial spaces like breakout spaces, AV rooms, retail or hotels.
Dimming isn’t a problem, with options for switchDim, DALI dimming and CASAMBI, this architectural downlight can become a part of the wireless lighting scheme.
Light Source Information
· Recessed
· Output: up to 2 x 1270lm
· 50,00hrs,
· LED Efficiency of 93 lm/W
· Colour Temperature 2700K/ 3000K / 4000K
· CRI 92
· Part L compliant
Design
· Dimension 155 x 85 mm
· Standard Bezel finish White, Black
· Baffle finish: White, Black, Matt and Gold
· Made from die-cast aluminium, injection moulded PC
· IP20
Optics
· Optical lens
· Beam Angle: 12° / 24°/36°/60°
· Accessories: Honeycomb, Frosted glass, Clear glass
Dimming
· Phase DIM
· DALI DIM
· SwitchDIM
Integrated Controls
· Casambi
Miscellaneous
· Emergency - EM with a remote indicator
· 5 years warranty
299 Lighting reserve the right to change the specification of any product without notice or public announcement.
Data Sheet
LDT Files - Upon Request
Installation Instructions - Upon Request
BIM Files - Upon Request
TM65 Report - Upon request
