Versatile
Thanks to its superb build quality, excellent performance, and high visual comfort it is a perfect linear LED lighting system for stimulating working environments and schemes looking to achieve LG7 compliance.
RECESSED LINEAR LIGHT
The RIO Recessed Trim is the ultimate performance driven linear profile. Designed with simplicity and attention to detail, the RIO is contemporary and stylish. Used as an individual luminaire in standard size, or a continuous linear lighting system, the RIO adds a contemporary feel to any workplace or architectural space. Specified with the opal diffuser, the RIO Recessed creates clean lines of light, in crisp plasterboard. On the other hand, a bold architectural feature can be designed by simply using a black trim. Add a black diffuser and you have a truly unique architectural feature! But the RIO Recessed Trim is not just a practical approach to recessed office lighting. With its variation in mounting styles and diffusers, the RIO is a perfect example of flexible linear LED lighting. A true all-rounder, it is equally at home in an office and as an architectural linear lighting.
The RIO can be also specified as asymmetric wall washer for applications where illuminating a vertical wall is required, such as accent lighting or retail lighting. The clean-cut illuminated corner modules invite you to play and create unique shapes in made-to-measure lengths. It is a perfect linear solution for joinery details and custom made ceilings. And the best thing about RIO? The super easy installation! The click-in gear tray make the RIO the perfect straight out of the box LED linear lighting solution.
The RIO has become an early adopter of the latest LED Tunable White technology, giving the user the freedom to select any custom colour temperature between 2700K and 5000K with a proven positive effect on health and wellbeing. The RIO is available in 3 standard colours or 'stand out from the crowd' and choose any RAL colour or vinyl wrap to match your interiors design. Ideal as a premium surface mounted linear lighting for Cat A and Cat B office fit-out and a flexible solution for bespoke schemes.
The RIO can be specified with both CASAMBI and Philips EasyAir to increase user control.
Light Source Information
· LED
· Direct Distribution
· LED outputs available from 14W 1,333lm up to 74W 7,071lm
· Efficiency of 94lm/W
· The Rio can achieve schemes of <19UGR, meeting the CIBSE, SLL and BCO guide to lighting standards.
· Colour Temperature 3000K | 4000K | Tunable White
· Internal Drivers supplied
· Part L compliant
Design
· Extruded aluminium profile
· IP20 Rated
· Recessed Ceiling Mounted
· Available in 7 standard sizes ranging from 860mm to 2260mm. Other sizes available on request 580mm-2260mm in 70mm increments
· Available in White, Black or Grey. Custom RAL available on request
Optics
· Opal Diffuser
· Microprismatic Diffuser
· Asymmetric Reflector
· Black Opal
· Modular Optics
Dimming
· Non-dimmable as standard
· DALI available on request
· Tunable White available on request. It uses DALI DT 8 control drivers
Integrated Controls (on request)
· CASAMBI · Philips EasyAir
Installation
· Can easily be connected into a system. Quick and simple power and control connection.
Miscellaneous
· 3hr Emergency available on request
· 2 year warranty
· Integral Emergency Dimensions Above 1266mm
299 Lighting reserve the right to change the specification of any product without notice or public announcement.
Thanks to its superb build quality, excellent performance, and high visual comfort it is a perfect linear LED lighting system for stimulating working environments and schemes looking to achieve LG7 compliance.
The design of the RIO lends itself perfectly to made to measure linear lighting solutions.
It gives the designer a true freedom creating a vast array of dimensional combinations.
Thanks to the wago connect system, the luminaire distributes edge-to-edge light with zero light bleed.
The click-in gear tray make the RIO the perfect straight out of the box LED linear lighting solution..
First in its class, the RIO is not just about being office lighting in a different body, it offers 5 different types of diffusers, the RIO presents a welcome change to the usual linear LED lighting.
All mounting styles of Rio can be easily upgraded with CASAMBI control, allowing faster and easier installation and commissioning. Putting the user in charge, wireless controls are a serious proposition for workplace future-proofing with increased energy saving and wellbeing.
All mounting styles of Rio can be easily upgraded with CASAMBI control, allowing faster and easier installation and commissioning. Putting the user in charge, wireless controls are a serious proposition for workplace future-proofing with increased energy saving and wellbeing.
